irregular shaped high temperature polycrystalline fiber products
irregular shaped high temperature polycrystalline fiber products
irregular shaped high temperature polycrystalline fiber products
Model
FV

Item specifics

Working Temperature
1400C-1700C
raw material
Polycrystalline Fiber
Color
White
Package
wooden carton
Chemical Composition
Al2O3+SiO2

Product review

Description

Characteristics

Good compression strength, tensile strength and bending strength

Accurate size

Low thermal conductivity, good thermal shock resistance

Heating and cooling fast

Good insulation effection

Product Application

Burner blocks

Observation port

Heating element support

Flue and pipe lining

Insulation layer

Anchorage and furnace door

Hot top furnace

Laboratory electric furnace inner tank

Product Specification

Items

FV-1600

FV-1700

FV-1800

Classification Temperature(C)

1600

1700

1800

Bulk Density(kg/m3)

300-600

300-600

300-600

Linear Shrinkage(%)

<2

(1450C×24hrs)

<1

(1550C×24hrs)

<1

(1650C×24hrs)

Chemical

Composition
%

Al2O3

63.5

75

78

Al2O3+SiO2

>99

>99

>99.5

Fe2O3

<0.1

<0.1

<0.1
