Bio Soluble Fiber Board
Review
Description
Descriptions
Bio Soluble Boards are made from soluble fiber and a small amount of organic binder. Due to the high fiber content, Bio Soluble Boards are strong, lightweight and thermal shock resistant. Thickness over 50mm is obtained by bonding resistance two thinner sheets.
Features
Waterproof
Resistant to thermal shock
Low thermal conductivity
Precise geometry and close tolerances
Homogeneous structure, easy for machining
Non-brittle
High fiber content
Lightweight, low heat storage
Easy to install
Typical Applications
Refractory lining for industrial furnaces in walls, roofs, doors, stacks, etc
Combustion chamber liners, boilers and heaters
Back-up insulation for brick and monolithic refractories
Transfer of molten aluminum and other nonferrous metals
Expansion joint boards
Barrier against flame or heat
Hot face layer for high velocity or abrasive furnace atmosphere
Atmosphere
Typical Parameters
BIO SOLUBLE BOARD | 1100-BOARD | 1300- BOARD | |
Physical properties | Classification Temperature(℃) | 1100 | 1300 |
Bulk Density (kg/m³) | 300/320 | 300/320 | |
Water Content(%) | 0.8 | 0.8 | |
Cold Crushing Strength(MPa) | 0.13 | 0.13 | |
Organic Material Content(%) | 6.5 | 6.0 | |
Permanent Liner Change (%) (1000℃X24h) | 1.2 | 1.0 | |
Thermal Conductivity (W/mK) | 200℃ | 0.052 | 0.060 |
400℃ | 0.080 | 0.100 | |
600℃ | 0.120 | 0.130 | |
KNB | 25 | ||
Note：KNB=（Na2O+K2O+CaO+MgO+BaO）*100 | |||
